• Cells Per Unit: 6
• Voltage Per Unit: 12
• Capacity: 100Ah @10hr-rate to 1.80V per cell @ 25℃
• Weight: 31KG
• Max. Discharge Current: 1000A (5 sec)
• Internal Resistance: Approx. 5.5mΩ
• Recommended Maximum Charging Current Limit: 30A
• Operating Temperature Range: Discharge: -20℃~60℃ Charge:0℃~50℃ Storage:-20℃~60℃
• Normal Operating Temperature Range: 25℃ ± 5 ℃
• Float charging Voltage: 13.6 to 13.8V DC/unit Average at 25℃
• Equalization and Cycle Service: 14.4to 14.6V DC/unit Average at 25℃
• Self Discharge: Front terminal batteries can be stored for more than 6 months at 25℃. Self-discharge ratio less than 3% per month at 25℃. Please charge batteries before using.
•Size: 410*109*293MM
